Universal Audio Apollo Twin X Quad ออดิโออินเตอร์เฟส
สินค้าของแท้ 100% นำเข้า ลดราคา
73,400฿
Apollo Twin X allows musicians and producers to easily track, overdub, and mix with elite-class A/D and D/A conversion, two Unison-enabled preamps, and available DUO or QUAD Core realtime UAD plug-in processing — all in a desktop Thunderbolt 3 audio interface for Mac and Windows.
Built upon UA’s 60-year heritage of audio craftsmanship, Apollo Twin X confidently outperforms everything in its class with 127 dB D/A dynamic range, along with an included bundle of UAD analog emulation plug-ins and LUNA Recording System, giving you a fully-stocked analog studio, right on your desktop.
แชทพูดคุย
Loading...
UAD Apollo Twin X Quad ออดิโออินเตอร์เฟส
การผสานรวมฮาร์ดแวร์และซอฟต์แวร์ระหว่างไมค์ปรีแอมป์ของ Apollo และ UAD DUO หรือ QUAD Core DSP Acceleration แบบออนบอร์ด เพียงวางปลั๊กอินปรีแอมป์ Unison เข้ากับอินพุตไมโครโฟนของคุณในซอฟต์แวร์ Apollo Console และปลั๊กอินจะกำหนดค่าอิมพีแดนซ์ของอินเทอร์เฟซ Apollo ใหม่ ดังนั้นคุณจึงสามารถสัมผัสกับเสียงคลาสสิกของปรีแอมป์ไมโครโฟนที่ดีมาก
คุณสมบัติ :
- ด้วยโปรเซสเซอร์สี่ UAD-2 เพื่อการบันทึกเสียงที่แทบไม่มีความหน่วงแฝง
- ตัวแปลง AD / DA 24 บิต / 192 kHz
- ปรีแอมป์ไมโครโฟน Unison 2 ตัว
- พลัง Phantom: +48 V
- ไมโครโฟนแบบทอล์คแบ็คในตัว
- ช่วงไดนามิก: 127 เดซิเบล
- ตรวจสอบฟังก์ชั่นด้วยการควบคุมสำหรับ Mono, Mute, DIM และ ALT
- ออกแบบ: ตั้งโต๊ะ
| SYSTEM | |
| I/O Complement | |
| Microphone Inputs | Two |
| High Impedance (Hi-Z) Instrument Inputs | One |
| Analog Line Inputs | Two |
| Analog Line Outputs (DC coupled) | Two (four including Monitor outputs) |
| Analog Monitor Outputs (DC coupled) | Two (one stereo pair) |
| Headphone Output | One stereo |
| Digital Input | One (ADAT or S/PDIF, selectable) |
| Thunderbolt 3 Port | One |
| A/D – D/A Conversion | |
| Simultaneous A/D conversion | Two channels |
| Simultaneous D/A conversion | Six channels |
| Supported Sample Rates (kHz) | 44.1, 48, 88.2, 96, 176.4, 192 |
| Bit Depth Per Sample | 24 |
| Analog Round-Trip Latency | 1.1 milliseconds @ 96 kHz sample rate |
| Analog Round-Trip Latency through four UAD legacy plug-ins (included) via Console software | 1.1 milliseconds @ 96 kHz sample rate (no additional latency via Realtime UAD Processing) |
| ANALOG I/O | |
| Microphone Inputs 1 & 2 | |
| Frequency Response | 20 Hz – 20 kHz, ±0.05 dB |
| Dynamic Range | 123 dB (A–weighted) |
| Total Harmonic Distortion + Noise | -115 dB (1 kHz @ -1 dBFS) |
| Maximum Input Level (PAD on) | 25.6 dBu |
| Default Input Impedance | 5.4K Ohms (variable via Unison plug-ins) |
| Gain Range | +10 dB to +65 dB |
| Pad Attenuation (switchable per input) | 20 dB (variable via Unison plug-ins) |
| Phantom Power | +48V (switchable per mic input) |
| Connector Type | XLR Female, pin 2 positive (Combo XLR/TRS) |
| Hi-Z Input | |
| Frequency Response | 20 Hz – 20 kHz, ±0.05 dB |
| Dynamic Range | 121 dB (A–weighted) |
| Total Harmonic Distortion + Noise | -108 dB (1 kHz @ -1 dBFS) |
| Maximum Input Level (at minimum gain) | 12.2 dBu |
| Default Input Impedance | 1M Ohms (variable via Unison plug-ins) |
| Gain Range | +10 dB to +65 dB |
| Connector Type | ¼” Female TS Unbalanced |
| Line Inputs 1 & 2 | |
| Frequency Response | 20 Hz – 20 kHz, ±0.05 dB |
| Dynamic Range | 122 dB (A–weighted) |
| Total Harmonic Distortion + Noise | -114 dB (1 kHz @ -1 dBFS) |
| Maximum Input Level (at minimum gain) | 20.2 dBu |
| Default Input Impedance | 10K Ohms |
| Gain Range | +10 dB to +65 dB |
| Connector Type | ¼” Female TS Unbalanced |
| Line Output 1 & 2 | |
| Frequency Response | 20 Hz – 20 kHz, ±0.05 dB |
| Dynamic Range | 126 dB (A–weighted) |
| Total Harmonic Distortion + Noise | -117 dB (1 kHz @ -1 dBFS) |
| Maximum Output Level | 20.2 dBu |
| Output Impedance | 100 Ohms |
| Connector Type | ¼” Female TS Unbalanced |
| Monitor Outputs L & R | |
| Frequency Response | 20 Hz – 20 kHz, ±0.05 dB |
| Dynamic Range | 127 dB (A–weighted) |
| Total Harmonic Distortion + Noise | -117 dB (1 kHz @ -1 dBFS) |
| Maximum Output Level | 20.2 dBu |
| Output Impedance | 100 Ohms |
| Connector Type | ¼” Female TS Unbalanced |
| Stereo Headphone Output | |
| Frequency Response | 20 Hz – 20 kHz, ±0.05 dB |
| Dynamic Range | 124 dB (A–weighted) |
| Total Harmonic Distortion + Noise | -98 dB (1 kHz @ -1 dBFS) |
| Maximum Output Level | 96 mW RMS |
| Connector Type | ¼” Female TRS Stereo |
| DIGITAL INPUT | |
| Connector Type | Optical TOSLINK JIS F05 |
| S/PDIF | |
| Format | IEC 958 |
| Supported Sample Rates (kHz) | 44.1, 48, 88.2, 96 |
| S/PDIF Input Channels | Two (Stereo L/R) |
| ADAT | |
| Format | ADAT Digital Lightpipe with S/MUX |
| Supported Sample Rates (kHz) | 44.1, 48, 88.2, 96, 176.4, 192 |
| ADAT Input Channels @ 44.1 kHz, 48 kHz | Channels 1 – 8 |
| ADAT Input Channels @ 88.2 kHz, 96 kHz | Channels 1 – 4 |
| ADAT Input Channels @ 176.4 kHz, 192 kHz | Channels 1 – 2 |
| Clock Synchronization Sources | |
| Internal, ADAT, S/PDIF | Conditional per selected digital input type |
| ELECTRICAL | |
| Power Supply | External AC-to-DC Power Supply, Level VI compliant |
| AC Input Connector Type | IEC C8, non-polarized |
| AC Requirements | 100V – 240V AC, 50 – 60 Hz |
| DC Connector Type | Male plug, 2.1 mm x 5.5 mm, center positive |
| DC Requirements | 12 VDC, ±5% |
| Maximum Power Consumption | 15 Watts (when portable host computer not charging) |
| ENVIRONMENTAL | |
| Ambient Temperature Range | 32º to 104º F (0º to 40º C) |
| MECHANICAL | |
| Dimensions | |
| Width | 6.31” (16.03 cm) |
| Height | 2.60” (6.6 cm) |
| Depth, Chassis Only | 5.86” (14.88 cm) |
| Depth, Including Knob & Jack Protrusions | 6.20” (15.75 cm) |
| Shipping Box (Length x Width x Height) | 8” x 8” x 5.5” (20.32 cm x 20.32 cm x 13.97 cm) |
| Weight | |
| Shipping Weight (with box & accessories) | 3.85 pounds (1.75 kg) |
| Weight (bare unit) | 2.35 pounds (1.07 kg) |
| Package Contents | |
| Apollo Twin X Unit (DUO or QUAD) | |
| External Power Supply | |
| AC Power Cable (IEC C7, non-polarized) | Region Specific (USA, EU, UK, ANZ, or Japan) |
| Getting Started URL Card | |
- ขอสงวนสิทธิ์ในการเปลี่ยนแปลงข้อมูลสินค้า และราคาโดยไม่ต้องแจ้งให้ทราบล่วงหน้า
