Dual Camera System |
|
Wide Camera: |
8MP Camera |
|
Field of view:120° |
|
4x e-PTZ Camera |
Telephoto Camera: |
|
|
8MP Camera |
|
Field of view:90° |
|
10x Hybrid Zoom (3.5x optical, 3x digital) |
|
Horizontal Rotation Angle:+25°/-25° |
|
Vertically Rotation Angle:+16°/-16° |
Electric Privacy Shutter |
|
Intelligence Features |
|
|
Auto Framing |
|
Speaker Tracking |
Audio |
|
|
Built-in 8 MEMS microphone array |
|
Support extention mic |
|
Two Built-in 5W high fidelity speaker |
|
Yealink Noise Proof Technology |
|
Beamforming directed voice pickup technology |
|
Full-duplex |
|
Echo cancellation |
Operating System |
|
|
Android 9.0 |
Meeting Features |
|
|
Calendar |
|
One-click join |
Meeting collaboration |
Content sharing |
|
Whiteboard |
Meeting control: |
Add participates |
|
Hold/Resume |
|
Camera On/Off |
|
Mute/Unmute |
|
Volume Up/Down |
|
Hang up |
Teams Edition |
|
|
Microsoft DM |
|
Proximity join |
Zoom Edition |
|
|
Zoom DM |
|
Direct sharing |
Video Standard and Network Suitability |
|
Video codecs: |
H.264 High profile, H.264 SVC, H.264 |
Network and Security Features |
|
|
Built-in dual-band Wi-Fi (2.4GHz/5GHz) |
|
Built-in Bluetooth |
|
IPv4 and IPv6, DHCP/static IP |
|
HTTP/HTTPS web server |
|
SRTP/TLS, AES 256-bit encryption |
QoS: |
802.1p/q, Diff-serv |
|
VLAN, LLDP |
|
IEEE802.1X |
|
EAP-MD5/EAP-TLS |
|
PEAP-MSCHAPv2 |
|
EAP-TTLS/EAP-MSCHAPv2 |
Network diagnosis: |
Ping, Trace route |
|
Time and date synchronization using SNTP |
|
Simple Certificate Enrollment Protocol (SCEP)* coming soon |
Connections |
|
|
2 x HDMI output (CEC supported) |
|
HDMI input (through the VCH51 Sharing Kit) |
|
1 x Line-in (3.5mm) |
|
1 x Line-out (3.5mm) |
|
2 x USB 2.0 |
|
1 x 10/100M/1000M Ethernet port |
|
1 x Yealink extension port (RJ-45) |
|
1 x Power port |
|
1 x Security lock slot |
|
1 x Reset slot |
Other Physical Features |
|
External Yealink Power Adapter: |
AC 100~240V input and DC 48V/0.7A Output |
USB Output: |
5V—0.5A |
Power consumption (PSU): |
Idle < 13W; Normal operating: 15W; MAX: 16W |
Dimension (W.D.H): |
700 mm x 98 mm x 121 mm |
Operating humidity: |
10~95% |
Operating temperature: |
0~40°C |
Storage temperature: |
-30~70°C |
MeetingBar A30 Package |
|
Package contents: |
MeetingBar A30 endpoint |
|
3m Ethernet cable |
|
2 x 1.8m HDMI cable |
|
Mounting Bracket and Accessories |
|
Quick Start Guide |
Controller (optional): |
CTP18 Touch Panel |
|
VCR20 Remote Control |
Content sharing(optional): |
VCH51 Sharing Kit (HDMI/USB-C) |
|
WPP20 Wireless Presentation Pod |
Carton Meas: |
903*325*306mm |
MeetingBar A30 + CTP18 Package |
|
Carton Meas: |
923*495*327mm |
