Interface |
Control Unit: USB 2.0 High Speed (B), Bluetooth, NFC (Near Field Communication), |
|
Audio Input terminal (stereo RCA pin), Audio Output terminal (stereo RCA pin), |
|
External speaker terminal (RCA pin) x 2, Power terminal, Microphone terminal, |
|
Microphone: Input and output terminals |
Power consumption (max) |
20 W (one connected microphone), 35 W (five connected microphones) |
Power source |
[U.S.A. and Canada] AC 120 V (60 Hz), [UK, Europe and Russia] AC 220 – 240 V (50 Hz) |
Operating environment |
Temperature: 0 – 40° C (32 – 104° F), Humidity: 20 – 85% (no condensation) |
Dimensions |
Control Unit (W x H x D): 332 x 95 x 162 mm (13.1 x 3.74 x 6.38 in), |
|
Microphone (W x H x D): 136 x 36 x 136 mm (5.35 x 1.42 x 5.35 in) |
Weight |
Control Unit: 1.8 kg (4.0 lbs) |
|
Microphone: 0.4 kg (0.9 lbs) |
Supported OS |
Windows 11 |
|
Windows 10(32bit/64bit) |
|
Windows 8.1(32bit/64bit) |
|
macOS 12 |
|
macOS 11 |
|
macOS 10.15 |
Voice guidance |
English, Japanese, Chinese, Korean, French, Spanish, German |
Accessories |
Power cable 3 m (9.8 ft) |
|
USB cable 5 m (16.4 ft)) |
|
microphone cable 5 m (16.4 ft)) |
|
Quick Start Guide |
Other |
Firmware update (transferred from PC/Mac through USB) |
|
Optional extension microphone (YVC-MIC1000EX) |
Audio |
|
Microphones |
Unidirectional Microphones x 3, 360° coverage |
Speakers |
Full-range Speaker x 1 |
Maximum volume |
95 dB (0.5 m (1.6 ft)) |
Frequency bandwidth |
100 Hz – 20,000 Hz |
Signal processing |
Adaptive echo canceller, Noise reduction, Automatic tracking, |
|
Automatic gain control, Automatic room EQ, |
|
Dereverberation, Automatic audio tuning |
Input specifications |
|
Terminal |
AUDIO IN |
MODE |
CONFERENCE SYSTEM |
SIGNAL LEVEL |
– |
Standard Level |
-22.4 dBV |
Maximum Input Level |
1.6 dBV |
Terminal |
AUDIO IN |
MODE |
PA MICROPHONE |
SIGNAL LEVEL |
LINE |
Standard Level |
-22.4 dBV |
Maximum Input Level |
1.6 dBV |
SIGNAL LEVEL |
MICROPHONE |
Standard Level |
-62.4 dBV |
Maximum Input Level |
-38.4 dBV |
Output specifications |
|
Terminal |
AUDIO OUT EXTERNAL SPEAKER |
Standard Level |
-23.5 dBV |
Maximum Output Level |
0.5 dBV |
Standard Level |
-23.5 dBV |
|
0.5 dBV |
